Slipform pavers

---

INTRODUCTION OF CP 6000 & CP8000 SLIPFORM CONCRETE PAVERS

The slipform concrete paver is based on the advanced technology of PAV-SAVER introduced from the American PRO-HOFF company. The Sytechs slipform concrete pavers are designed with paving widths ranging from 3.4 to 6 meters and 4.25 to 8 meters. It can be widely used in urban and rural roads, high-grade highways, high-speed railway passenger lines, squares, docks, water conservancy and other cement concrete pavement engineering projects.

This slipform paver is fully hydraulic with high power and two crawler tracks. It is equipped with automatic driving and automatic leveling control systems. It can complete concrete paving, scraping, vibrating, tamping and squeezing at one time during operation.

It can press the pavement and other processes, and can complete the middle steel bar insertion, side steel bar insertion and other processes.

The optional super trowel can eliminate the unevenness left on the surface of the concrete pavement through the horizontal and vertical compound movement of the trowel, thereby making it smoother. Economically achieve a smoother road surface.

Main operating performance characteristics and configuration introduction

● Wide scraping plate with fine adjustment mechanism to ensure paving surface flatness.
● Special angle cutting mechanism for good pavement shaping
● Simultaneous operations of scraping, vibrating, tamping, shaking, extruding and shaping, during which, reinforced steel can be inserted in the middle or at the LR/LH sides.
● Full hydraulic independent drive, micro computer with display and self diagnostic capability.
● Auto leveling and tracing system to ensure paving flatness straightness and smoothness at road bends
● Ergonomically designed with smart controls for operational comfort and easy operation
● Imported key components to ensure machine reliability and prolonged service life of the paver

---
